Handheld Shining 3D Scanner Pro+ for Mould
259000.00฿229000.00฿
Handheld Shining 3D Scanner Pro+ for Mould
The Shining 3D Scanner Pro+ is a new multi-function scanner. The scanning software has excellent user friendly, can guide you to complete the scanning process.
Features
1. There are four modes (handheld HD, handheld rapid, fix automatic and fixed free), you could choose in different situations. The 3D scanner is a multi- function scanner.
2. The 3D scanner connect with color camera. So the scanner will quickly capture true color of the object, and restore it.
3. The speed of 3D scanner is high. The handheld can be 10 frames/ second. It can be used in large portrait.
4. The 3D scanner could be used in many fields, such as R&D, education, preservation of cultural relics, art, biomedicine, crafts and so on.
Parameters
Model | EisScan-Pro+ | |||
Scan mode | Handheld HD scan | Handheld rapid scan | Automatic scan(Available with | Fixed can(Available with |
Scanning short accuracy | 0.1mm | 0.3mm | 0.05mm | 0.05mm |
Scan speed | 550,000 points/sec | 450,000 points/sec | Single scan: < 2 s | Single scan: < 2 s |
Point distance | 0.2 mm-3 mm | 0.7-3 mm | 0.24 mm | 0.24 mm |
Align mode | Markers or Features | Feature, | Markers, Feature, Turntable, Manual, Turntable coded targets | Feature, Manual |
Texture scan | No | Yes (Available with Color Pack) | Yes (Available with Color Pack) | Yes (Available with Color Pack) |
Outdoor operation | No( avoid direct sunlight) | |||
Special Scan Object | For transparent and reflective objects, please spray powder before scanning. | |||
Single Scan Range | 300×170 mm | |||
Light source | White LED | |||
Print data output | support | |||
Data Format | OBJ,STL,ASC,PLY, 3MF | |||
Scan head weight | 0.8kg | |||
System support | Win7,Win8,Win10 64bits | |||
Application
Some auto parts, simply use the traditional test method (such as checking fixture, fixture, etc.) is very complicated, time consuming. Traditional method can not test some complex structure such as flexible components quickly. Therefore, the auto parts detection often need to use a variety of test way, the non-contact 3 d scanners is an indispensable tool.
The 3d scanner is widely used in the development and manufacture of auto parts.
Packaging and Delivery
1. Inner package: packed by plastic sheet, water-proof and dampproof.
2.Outside package: packed by plywood case.
3. Delivery term : delivered within 3-5 working days after receiving deposit.
